B-13N Rail by Zenitco - Receiver-Mounted Optics Platform with Dovetail Interface

Brand: Zenitco
Product Code: Zen-B-13N
Availability: In Stock
SKU: Zen-B-13N
MPN: Zen-B-13N
  • $349.00
Available Options
0

Zenitco B-13N Side-Mount Receiver Rail - Quick-Detach Picatinny Optics Mount for SVD-Pattern Platforms

Genuine Zenitco | CNC-machined D16T aluminum | 200 mm Picatinny rail | Black, Desert & Golden khaki
In short: a genuine Zenitco B-13N - a one-piece milled side mount that clamps onto the standard side dovetail (side-rail) base of SVD-pattern platforms and Tiger carbines and forms a 200 mm Picatinny rail over the receiver for optics. It uses twin quick-detach levers with double locking for a repeatable, return-to-zero fit and does not block the iron sight line. Machined from D16T aluminum; about 210 g. Available in black, desert and golden khaki.

The B-13N is the SVD-pattern version of Zenitco's side-mount rail. It slides onto the factory side-rail (dovetail) base, locks with two levers, and puts a full 200 mm Picatinny rail above the receiver so you can run a scope, red dot, night or thermal device - or a combination - while keeping the mechanical sights usable.

It goes on and comes off quickly and repeatably thanks to the twin double-locking levers. A genuine Zenitco factory part machined from D16T aluminum; it measures about 73 x 43 x 205 mm, weighs about 210 g, and ships with two hex keys and a manual. Rated for a working temperature range of -50 to +50 C.

Compatibility Note: Fits SVD-pattern platforms and Tiger (Tigr) carbines that have the standard side-rail (dovetail) mounting base on the receiver. Confirm your receiver has the side base before ordering.

Key Advantages

  • Genuine Zenitco factory part with exact original fit
  • Full 200 mm Picatinny rail over the receiver for optics
  • Twin quick-detach levers with double locking - repeatable, return-to-zero
  • Sits low - does not block the iron sight line
  • CNC-machined D16T aluminum - strong and light (about 210 g)
  • Available in black, desert and golden khaki

Technical Specifications

BrandZenitco
Part TypeSide-mount receiver optics rail
FitsSVD-pattern platforms / Tiger carbines with side dovetail base
MountingStandard side-rail (dovetail) base - twin quick-detach levers, double lock
RailPicatinny top rail, 200 mm (over receiver)
MaterialD16T aluminum alloy (CNC-milled)
Weight~210 g
Dimensions~73 x 43 x 205 mm
IncludedBracket, 2 hex keys, manual
Operating Temp-50 to +50 C
FinishBlack / Desert / Golden khaki
MPNZen-B-13N
ConditionNew

Frequently Asked Questions

What is the Zenitco B-13N?
It is a genuine Zenitco side mount that clamps onto the standard side dovetail base of SVD-pattern platforms and forms a 200 mm Picatinny rail over the receiver for optics.
What does it fit?
SVD-pattern platforms and Tiger (Tigr) carbines that have the standard side-rail (dovetail) base on the receiver.
Is it quick-detach?
Yes - it uses twin levers with double locking, so it goes on and off quickly and returns to zero. It does not block the iron sights.
How is it different from the B-13?
The B-13N is made for the SVD-pattern side base (SVD, Tiger), while the standard B-13 fits AK-pattern receivers. The B-13N is a little larger and uses twin levers.
What is it made of?
CNC-machined D16T aluminum alloy. It weighs about 210 g and measures about 73 x 43 x 205 mm.
Is this a genuine Zenitco part?
Yes - it is an original Zenitco part with guaranteed US delivery.
Add a quick-detach optics rail to your SVD-pattern build - order the genuine Zenitco B-13N side mount.
In Stock | Guaranteed US Delivery | Genuine Zenitco Part
Related: B-13 Rail (AK-pattern) | B-13K Rail | B-33 Receiver Cover Rail

General

Brand Zenitco
Manufacturer Part Number (MPN) Zen-B-13N
Condition New
Intended Use Sport shooting / Training
Material D16T aluminum alloy (CNC-milled), coated
Color / Finish Black / Desert / Golden khaki
Weight 210 g (+/- 10 g)
Dimensions (L x W x H) mm 73 x 43 x 205 mm (+/- 5 mm)

Mounting & Rails

Mounting Standard side-rail (dovetail) base; twin quick-detach levers with double lock
Rail Type Picatinny top rail, 200 mm (over receiver)
Function Side-mount receiver optics rail for SVD-pattern platforms / Tiger carbines; quick-detach, return-to-zero
