Zenitco B-13K V2.0 Quick-Release Rail for Kord
- $599
Available Options
In short: Zenitco B-13K V2.0 is a dedicated Kord mounting system. Its separate base secures to the original side dovetail, while the upper bracket locks onto that base with two adjustable quick-release levers. It forms a 184 ± 5 mm top Picatinny rail and includes a preinstalled B-2L side rail.
Compatibility hierarchy
| Compatible model | Required host interface | Included intermediate interface |
|---|---|---|
| Kord | Original side dovetail | B-13K base with two adjustable quick-release levers |
Selection checkpoint: B-13K V2.0 is documented specifically for Kord. It is not the B-13 side-rail model used on other platform families.
V2.0 mounting system
The base is secured first with its two mounting screws. The upper bracket then attaches to the base through two locking levers. Each lever has a retainer and an adjustable screw, allowing play to be removed without altering the base position.
- Top interface: 184 ± 5 mm Picatinny rail for compatible sighting components.
- Side interface: mini Picatinny section provided by the included B-2L and its screws.
- Removal: the upper bracket can be released from the installed base using both locking levers.
Technical specifications
| Compatible model | Kord |
|---|---|
| Host interface | Original side dovetail |
| Top rail length | 184 ± 5 mm |
| Weight | 543 ± 15 g |
| Operating temperature | −50 to +50 °C |
| Finish options | Black; Desert |
| Manufacturer warranty period | 60 months for storage and operation |
Installation outline
- Release both locking levers and separate the upper B-13K bracket from its base.
- Loosen the two base screws, position the base on the original Kord side dovetail and tighten both screws.
- Place the upper bracket on the installed base and close both locking levers.
- If movement remains, press each screw retainer and turn the adjustment screw clockwise until the movement is removed; then confirm that the retainer engages the screw notch.
What's in the Box
| Zenitco B-13K V2.0 upper bracket | × 1 |
| B-13K base | × 1 |
| B-2L rail section with screws, preinstalled | × 1 |
| Hex key | × 1 |
| Operating manual | × 1 |
Frequently asked questions
Which model is B-13K V2.0 designed for?
The manufacturer documents it specifically for Kord with the original side dovetail.
Does the package include the dovetail base?
Yes. The B-13K base and its mounting system are included.
Is there a side accessory rail?
Yes. One B-2L rail section with its screws is preinstalled on the side.
How is the upper bracket removed?
Open both adjustable quick-release levers and lift the upper bracket from the installed base.
